Explosion Suppressant Kit

Explosion Suppressant Foam Fitting Kit

NATO Stock Number: NSN 4920-66-158-7331

Drawing Numbers: AM15620-1 (2015), AL060040-1 (2005)

Cage Code References: Z00V5, Z5513, Z8848

Used to facilitate installation of Explosion Suppressant Foam Blocks in aircraft fuel tanks.

CDPTFE is a conductive form of PTFE, but does not contain carbon or graphite.

By grounding the CDPTFE sheet and personnel to the body of the aircraft, electrostatic charge can be reduced through effective equipotential bonding of otherwise isolated conductors.

The ESFFK-1 kit comprises of:

• 1 off 1m x 300mm x 2mm (nominal dim's) CDPTFE sheet with ''hand hole'' and stamped with serial number.
• 2 off 10mm snap-stud fitted
• CCJ10
• BG
• Boxed as a kit with C of C; includes the resistance value of the assembled kit.

MOQ - 4 kits and to be ordered in multiples of 4 kits
