CADSTAT Static Dissipative / Anti-static 3 Layer Bench Matting
Our 2LBM series is a high-quality ESD-safe anti-static mat built to last in all electronic workshops. The 3 layers provide extra protection to your work surface and the lay-flat nitrile rubber prevents curling, ensuring a long lifecycle.
Meets relevant International Static Control Standards, including:
- IEC 61340-5-1
- ANSI/ESD S20.20
Blue 3-layer synthetic rubber:
- Nominal width: 1.2m (+/- 10mm)
- Nominal length: 10m
- Nominal 3mm (+/- 0.5mm) thick
- Dissipative top & bottom: blue,with a typical resistance <109 Ohms @ 100V
- Conductive middle: black with a typical resistance <106 Ohms @ 10V
- Typical useage range between -40 to +300°C
- Heat resistant to solder splash and short periods of 320°C
- Chemical resistant
- Hard wearing
- Excellent lay flat properties
